6 1/2" Bartell Tubular Strander 6 Wire

Model 6-B-62
Serial Number B62-6R-1421
Inside string up
Rated Speed: 2000 RPM
Suitable for reels of up to 6½” flange diameter x 4” overall width
Single wire size: 0.004”- to 0.011” (0.10 to 0.28mm)
Maximum finished cable size: 0.062” (1.57 mm)
Hex style guards with inspection windows
Spring lock (one side only / other side hole in cradle)
Dual wheel capstan
7 1/2 HP AC Motor
30" shaft style takeup
Footage Counter

(K11)
