Niehoff Fine Wire Drawing, Annealing and Spooling Line
Direction of wire travel: Left to right

Material: Copper or aluminum wire
Number of wires:1
Maximum size of entering wire: #12 AWG (2.05 mm)
Maximum finish wire size: #24 AWG (0.50 mm)
Minimum finish wire size: #30 AWG (0.25 mm)
Maximum line speed: 9000 FPM (45 m/sec)

Model: M-15 Drawing Machine
Serial number: 10.12706
Year of Manufacture 1975
Number of dies: 17
Number of draw-block shafts: 4
Drafting elongation: 21 % per die
Finish capstan: Separate
Draw-block / capstan material:Ceramic
Drawing lubricant system: Not included

Model: VG 10A3 Annealer
Annealer drive: Through V belts from main machine
Automatic voltage control: For acceleration / deceleration annealing
Annealing coolant system: Heat exchanger/circulation pump included

Model: SG 145 Spooler
Year of Manufacture 1973
Spooler drive: Independent motor and drive
Spooler arbor: Expanding type
Dancer: Machine mounted
Maximum flange diameter: 12” (300 mm)
Bore diameter:3” (76 mm)

Electrics:
Main motor / drive: Included, 45 kW DC
Annealer controls: Transformer, voltage control
Spooler motor / drive: Included
Operating Voltage: 460 V / 3 Ph / 60 Hz
