24C Spirka Braider, on Wire, Model 24N4.( 8 Avail)
|
Product Code:BRD319
Manufacturer:Spirka
Location: Wadesboro, North Carolina
|
|
|
24-Carrier Spirka Braider
On wire
Model: 24N4
Serial Number: 9127
Year of Manufacture: 1985
Maximum head speed: 80 RPM
Cable Diameter: 40.0 mm
Picks Range: 11.0 to 110
Bobbin capacity: 230 cubic cm
Materials: Copper, Steel, Kevlar, Phosphor bronze
3.5 kg Max. bobbin capacity
Tension Control: Wire Spring tension
Lay change by gears
Picks Range: 2.57 - 38.39 mm
Longitudinal taper under braider
Counter: Metric
Capstan Diameter: 900 mm (36")
Pay Off and Take Up: 630 mm (24")
For Reels: 26" flange diameter x 18" Overall width
Uhing traverse on take-up
Electrics: 415V / 50 Hz
machine No 9127
|
|
Wire & Plastic Machinery offers equipment: as is, test run and fully inspected, many machines can be reconditioned.
Items listed on the website are for infomational purposes only.
Please base your purchasing decision on
specific information you receive from your sales representative.
|
|
